切捆条机系列
全自动封闭式除尘分切机
This machine is mainly suitable for leather, clothing, shoes and hats, bags, bikini, home textile fabrics, rain gear, luggage and other industries non-woven fabric, foam, leather, paper and reflective materials such as straight lines and 45 degrees bias cutting in different width .
产品特点
• Spindle and the circular cutter use the stepless speed change system, can work speed and slow speed and positive and negative turn switch control.
• Equipped with a double-sided knife grinding system, using diamond grinding, grinding wheel life up to two years, the blade does not need to be removed.Can sharpen the knife, the blade for a long time to keep sharp, to cut the quality.(And with the amount of vacuuming, keep the cloth and track clean.According to customer demand)
• Adopt imported ball slide track, parallel advance cutting stability adopt imported AC motor adjustment system stepless adjustment control cutting speed translation and not easy to wear.
• Operation interface USES LCD display screen, you can directly input several load cutting width and quantity Settings, and has manual and automatic conversion functions.
• Adopt fast discharging design, one step in place.Loading and unloading can be accomplished with only one action.
• This machine adopts the structure of rotating ball screw, grinding knife and cutting knife advance and reverse, which is 3:1 of the conventional machine speed.

产品应用
