• Precision four-column double-cylinder double-connecting rod automatic balancing mechanism, the cutting error of each cutting position is very accurate.

• This machine is suitable for continuous blanking of non-metallic coils with the same specifications and large quantities with the molding die. For example, it can be used in football, volleyball, tennis, sandpaper, medicine, insole, uppers and other industries.

• Microcomputer controls the transverse movement of the machine and the coordinated movement of the feeding shaft, so that the machine can automatically complete the blanking action of the material, the distance of the upper pressing plate can be adjusted and the feeding length can be adjusted, reducing the loss of the scrap material, saving nearly 10% of the raw material.

• Machine has a variety of working methods, such as inching, manual, automatic, workers only need to pick up finished materials, reduce frequent movement, improve work efficiency.

• Machine has a full plate die blanking mode, which can obtain materials, greatly reducing the consumption of materials and manual errors.

• Central automatic lubrication system ensures the cutting effect and improves the durability of the machine.

• Because the machine adopts microcomputer control automation, the whole machine only needs one worker, the production efficiency can be increased 4-5 times, and the electricity can be saved nearly 1/3.

• Setting mechanism, cooperate with cutting knife and cutting opening stroke setting, so that stroke adjustment is convenient.Special specifications can be customized.

• Machine is equipped with a material deviation correction device, which can control the overlapping edges of multi-layer materials to be neat and save materials.
